GVM-YU150R

GVM-YU150R

Industrial-grade film

And television full-color

The LED panel light of GVM-YU150R is a powerful light source

It adopts full RGB+WY five-color light source.

More colors can output a wider color gamut, thus providing tens of millions of rich and vivid colors.

High color rendering index

CRI 97+ & TLCI 97+

This can achieve accurate color rendering on the camera, and restore the most realistic object color.

It also provides you with natural and vivid shooting effects while obtaining professional results.

Can ensure color layout in the matrix system and RGBWY mixing in the beam area evenly without color separation

GVM-YU150R

This product is specially designed for senior photography enthusiasts.

App ntelligent control system Has 6 lighting modes :

CCT. HSI. RGB. GEL color paper, light source matching. and feld light effect.

Brightness. color temperature. hue, saturation, and RGB color

can be freely ortolld

Outstanding color

CRI 97+

Step-less adjustable

RGB 0°-360°

Color temperature

2000-10000K

Eash Side

Power of 150w

Smart connectivity

Lighting modes

GVM ControlAPP

6 modes

Dimming accuracy of 1000 levels

The adjustment range of GVM-YU150R brightness is 0.1%-100.0%, and the user can adjust the brightness accurately to 0.1%;

the finer dimming accuracy can provide smoother dimming process and more accurate colors;

with the new algorithm of GVM The model, even if the light intensity is adjusted in a large step,

it can also quickly and smoothly complete the dimming process.

APP Intelligent

Control System

APP control, which can be controlled by your ios and Android smart

mobile devices; At the same time, it supports Bluetooth Mesh networking,

and can work with GVM brand devices that support Mesh networking to

ready for group control.

RGB Multi-Color

RGB mode includes color gamut and adjustment bar; Color gamut selection:

select RGB value by touching the color gamut with your fingers,

so that the light color setting is faster and more intuitive;

Adjustment bar color selection: it can accurately adjust the changes of R,

G and B in the range of 0-255 to make the light change more accurate;

Bi-color Output

The color temperature from 2700k- 10000k or anywhere in between means

that you can quickly match the prevailing ambient or artificial light balance

with a simple twist of a knob.

Gel control mode

It includes 30 types of common color paper of Lee type and 30 types of common color paper of Rosco type,

so as to quickly adapt to the light effect of different shooting environments;

HSI control mode

HSI mode includes color pickup by color pickup disk and color pickup by camera;

Pick up the color from the color dial: touch the color dial with your fingers to

quickly and smoothly adjust hue (0 ~ 360 °) and sat (0 ~ 100%), so that the light has more colors;

Camera color pickup: obtain the hue and sat values corresponding to the environment through the camera anchor,

control the color change of the light, and make your scene light effect closer to the environment;

Source MODE

&

EFFECT MODE

Source Matching: Tungsten, HMI5600, HMI6000, Studiolamps, Sodium-

lamp, Halogen, Arclamp, Candle, Sunset/Sunrise, Daylight, Overcastsky,

CFL Cool White

Effects: Lightning, CCT Loop, Candle, Bad Bulb, TV, Paparazzi, Explosion,

Pulsing, Disco, Cop Car, Party, Hue Loop

DMX

Equipped with a standard DMX interface, it can realize the DMX control mode of low precision 8bit and high precision 16bit.

Using the built-in industry standard DMX-512 interface, the GVM-YU150R can

be integrated into more complex studio installations that require a standardized remote control method,

such as news sets, talk shows or entertainment productions. The unit is equipped with

two XLR-3P DMX ports (In/Out – Loop), allowing the panel to be connected to a DMX lighting console

Display

It has display and a stable system, Displays current settings, modes, and parameters.

Which supports 360° rotation and can effectively control light.

Intuitive user interface

Gvm-yu150r uses intuitive panel control interface to operate lamps easily and quickly.

The digital display displays all useful information for the user to adjust and customize the required values.

The three large selection knobs can be easily handled (even with gloves) to fine tune the required parameters.

Excellent

Brightness

Manufactured carefully to have over 97

CRI value and high brightness,

Ultra-high CRI 97+ helps to restore

Ultra-high CRI 97+ helps to restore

and enrich the color light

object providing a natural

and vivid shooting effect to you

Transport box

Gvm-yu150r panel and all its main components can be kept in the optional aluminum alloy box.

The enclosed foam liner can effectively protect the lamp body and accessories,

facilitating transportation and safe storage
